Cassette Round Flow

Light Commercial / Commercial R410A

Cassette Round Flow

  • Low noise level
  • Wi-Fi control (OPTIONAL) to remotely control the air conditioner
  • ‘Fresh air’ knockout is incorporated in the chassis to allow fresh air introduction of up to 20% of nominal unit air flow without compromising the cooling capacity. More than 20% of the air conditioner's thermal cooling capacity is penalised.
  • Sensor (OPTIONAL) detects real-time air conditions and movement of people
  • 8-way flow
  • On-Off card



Energy class in cooling: A +

Energy class in heating: A

Features

Wi-Fi (Optional)
wifi optional

Wi-Fi (optional)

A Wi-Fi connected smart air conditioning system allows you the flexibility and convenience of having complete control of
your AC unit from wherever you are with the "Haier Smart Air 2" app from your phone or tablet.

Sensor (Optional)
Eco Pilot Sensor (Optional)
The air conditioner will detect the intensity of the light, the movement of people and level of activity, automatically adjusting the cooling and enabling the reduction of energy consumption.
Fresh Air
Fresh Air
'Fresh air’ knockout is incorporated in the chassis to allow fresh air introduction of up to 20% of nominal unit air flow without compromising the cooling capacity.
Wi-Fi (Optional)
Wi-Fi (Optional)
Download the Haier Smart Air 2 app to an Apple or Android device and connect the equipment to your
device to control your system from anywhere at any time.
Quiet
Quiet
Power as well as comfort, and quiet operation matters whilst enjoying your free time. With a low noise level you can have it all.
8 Ways
8 Way Air Flow
Thanks to an 8 way flow of air , it is possible to ensure a
360-degree airflow without any blind spots.

Technical Specifications

Commercial R410A

Indoor Model No. Outdoor Model No. Output power - cooling Output power - Heating Energy Class: SEER Energy Class: SCOP IU size (mm) W x D x H OU Size (mm) W x D x H Panel
ABH090H1ERG 1U28GS2ERA(S) 8.5 (2.2 - 9.5) 9.0 (2.5 - 10.0) 5.81 (A+) 3.8 (A) 840x840x246 860x308x730 PB-950KB
ABH105H1ERG 1U36HS1ERA(S) 9.8 (2.2 - 11.2) 10.2 (2.5 - 11.8) 5.83 (A+) 3.8 (A) 840x840x246 948x340x840 PB-950KB
ABH125K1ERG 1U48LS1ERA(S) 12.1 (6.0 - 14.1) 13.1 (6.0 - 16.0) 5.4 (A) 5.4 (A) 840x840x288 1008x410x830 PB-950KB
ABH125K1ERG 1U48LS1ERB(S) 12.1 (6.0 - 14.1) 13.1 (6.0 - 16.0) 5.4 (A) 5.4 (A) 840x840x288 1008x410x830 PB-950KB
ABH140K1ERG 1U60IS2ERB(S) 12.8 (6.0 - 15.0) 14.5 (6.0 - 16.5) 5.4 (A) 5.4 (A) 840x840x288 948x340x1250 PB-950KB

The data shown is purely indicative and is subject to change. Buyers are advised to check the accuracy with the supplier before purchasing.

Documentation

Please select the document type in the list below to view the required documentation.

Technical Data

Wi-Fi Instruction Manual

CE Certificate

Installation Manual
